Fanconi-Associated Nuclease 1

(All numbering and residues are taken from first PDB file)

Run Details Domains Sequence Morph Domain Pairs Contact Graph

DynDom run details

  Property   Value
  Name Fanconi-Associated Nuclease 1
  Conformer 1
(PDB) 		4rea (B)
  Conformer 2
(PDB) 		4reb (A)
  Window Length 13
  Minimum ratio 1.0
  Minimum domain size 20

Domains

Domain Size Backbone RMSD
(A)		 Residues
1 184 0.57   550 - 552   822 - 1002
2 68 0.62   407 - 462   538 - 549
3 175 0.79   553 - 745   766 - 766
4 20 0.44   746 - 765
5 28 0.46   379 - 406
6 30 0.86   463 - 469   494 - 537

Sequence


           ________________________________405______________________________________________________462____________________________
 4rea(B) : EFPYYLRSFLVVLKTVLENEDDMLLFDEQEKGIVTKFYQLSATGQKLYVRLFQRKLSWIKMTKLEYEEIALDLTPVIEELTNAGFLQTESELQELSEVLELLSAPELKSLAKTFHLVNPN
         :
 4reb(A) : EFPYYLRSFLVVLKTVLENEDDMLLFDEQEKGIVTKFYQLSATGQKLYVRLFQRKLSWIKMTKLEYEEIALDLTPVIEELTNAGFLQTESELQELSEVLELLSAPELKSLAKTFHLVNPN
           ________________________________405______________________________________________________462____________________________

           _________________________________537_________549________________________________________________________________________
 4rea(B) : GQKQQLVDAFLKLAKQgIGAVILKRAKALAGQSVRICKGPRAVFSRILLLFSLTDSMEDElLVNLGRMEFPSYTINRKTHIFQDRDDLIRYAAATHMLSDISSAMANGNWEEAKELAQCA
         :
 4reb(A) : GQKQQLVDAFLKLA----------rAKALAGQSVRICKGPRAVFSRILLLFSLT------lLVNLGRMEFPSYTINRKTHIFQDRDDLIRYAAATHMLSDISSAMANGNWEEAKELAQCA
           _________________________________537_________549________________________________________________________________________

           ___________________________________________________________________________________________________________744__________
 4rea(B) : KRDWNRLKNHPSLRCHEDLPLFLRCFTVGWIYTRILSRFVEILQRLHMYEEAVRELESLLSQRIYCPDSRGRWWDRLALNLHQHLKRLEPTIKCITEGLADPEVRTGHRLSLYQRAVRLR
         :
 4reb(A) : KRDWNRLKNHPSLRCHEDLPLFLRCFTVGWIYTRILSRFVEILQRLHMYEEAVRELESLLSQRIYCPDSRGRWWDRLALNLHQHLKRLEPTIKCITEGLADPEVRTGHRLSLYQRAVRLR
           ___________________________________________________________________________________________________________744__________

           _________766____________________________________________________________________________________________________________
 4rea(B) : ESPSCKKFKHLFQQLPEMAVQDVKHVTITlCSVEELALAHYRRSGFDQGIHGEGSTFSTLYGLLLWDIIFMDGIPDVFRNACQAFPLDLCTDSFFTSRRPALEARLQLIHDAPEESLRAW
         :
 4reb(A) : ESPSCKKFKHLFQQLPEM----vKHVTIT-cSVEELALAHYRRSGFDQGIHGEGSTFSTLYGLLLWDIIFMDGIPDVFRNACQAFPLDLCTDSFFTSRRPALEARLQLIHDAPEESLRAW
           _________766____________________________________________________________________________________________________________

           ____________________________________________________________________________________________________________
 4rea(B) : VAATWHEQEGRVASLVSWDRFTSLQQAQDLVSCLGGPVLSGVCRHLAADFRHCRGGLPALVVWNSQSRHFKLVEVKGPNDRLSHKQMIWLAELQKLGAEVEVCHVVAV
         :
 4reb(A) : VAATWHEQEGRVASLVSWDRFTSLQQAQDLVSCLGGPVLSGVCRHLAADFRHCRGGLPALVVWNSQSRHFKLVEVKGPNDRLSHKQMIWLAELQKLGAEVEVCHVVA*
           ____________________________________________________________________________________________________________

Morph
Morph animation in progress.
Status: Initialising

This morph was created using the MorphIt_Pro protein morphing technique.
For more advanced options, right click on the model.


Show console


play backwards pause play forwards

Domain Pairs

Fixed Domain Moving Domain Rotation Angle Translation   (A) Closure Bending Residues
1 2 4.1 0.0 39.5   549 - 550 Bending Region Analysis
1 3 5.5 -0.4 95.7   552 - 553   766 - 822 Bending Region Analysis
1 4 9.3 1.1 0.3   765 - 822 Bending Region Analysis
2 5 7.1 -0.3 78.8   405 - 408 Bending Region Analysis
2 6 10.5 0.4 47.7   462 - 463   537 - 538 Bending Region Analysis
3 4 7.0 0.3 96.7   744 - 746   765 - 766 Bending Region Analysis

Dynamic Contact Graph

Conformer 1 Contact:
Residue 1 ———› Residue 2

Conformer 2 Contact:
Residue 2 ———› Residue 1

Movement classification: Hinge

Conformer 1 Contact:
Residue 1 ———› Residue 3

Conformer 2 Contact:
Residue 3 ———› Residue 1

Movement classification: Hinge

Conformer 1 Contact:
Residue 1 ———› Residue 4

Conformer 2 Contact:
Residue 4 ———› Residue 1

Movement classification:

No Contacts

Conformer 1 Contact:
Residue 2 ———› Residue 5

Conformer 2 Contact:
Residue 5 ———› Residue 2

Movement classification: Hinge

Conformer 1 Contact:
Residue 2 ———› Residue 6

Conformer 2 Contact:
Residue 6 ———› Residue 2

Movement classification: Hinge

Conformer 1 Contact:
Residue 3 ———› Residue 4

Conformer 2 Contact:
Residue 4 ———› Residue 3

Movement classification: Hinge
